Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 169/190
No. Content (words) Unit Comment
50
Generator active energy ( H.W.) kWh Double word
51
Generator active energy (L.W.)
52
Battery voltage V × 10
53
Internal fault 1 Bit 15 = 1 \
Bit 14 = 1 /
Generator overfrequency
Bit 13 = 1 \
Bit 12 = 1 /
Generator underfrequency
Bit 11 = 1 \
Bit 10 = 1 /
Generator overvoltage
Bit 9 = 1 \
Bit 8 = 1 /
Generator undervoltage
Bit 7 = 1 \
Bit 6 = 1 /
Internal
Bit 5 = 1 \
Bit 4 = 1 /
Battery undervoltage
Bit 3 = 1 \
Bit 2 = 1 /
Generator overload
Bit 1 = 1 \
Bit 0 = 1 /
Generator reverse power
54
Internal fault 2 Bit 15 = 1 \
Bit 14 = 1 /
Mains overfrequency
Bit 13 = 1 \
Bit 12 = 1 /
Mains underfrequency
Bit 11 = 1 \
Bit 10 = 1 /
Mains overvoltage
Bit 9 = 1 \
Bit 8 = 1 /
Mains undervoltage
Bit 7 = 1 \
Bit 6 = 1 /
Interface fault X1 to X5
Bit 5 = 1 \
Bit 4 = 1 /
Internal
Bit 3 = 1 \
Bit 2 = 1 /
Internal
Bit 1 = 1 \
Bit 0 = 1 /
Mains vector shift
55
Internal fault 3 Bit 15 = 1 \
Bit 14 = 1 /
Overcurrent level 2
Bit 13 = 1 \
Bit 12 = 1 /
Generator overspeed (pickup)
Bit 11 = 1 \
Bit 10 = 1 /
Incoming power 0 not reached
Bit 9 = 1 \
Bit 8 = 1 /
Unbalanced load
Bit 7 = 1 \
Bit 6 = 1 /
Generator overcurrent level 1
Bit 5 = 1 \
Bit 4 = 1 /
Interface fault Y1 to Y5
Bit 3 = 1 \
Bit 2 = 1 /
Maintenance call
Bit 1 = 1 \
Bit 0 = 1 /
Start failure
