Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 168/190 © Woodward
No. Content (words) Unit Comment
20
Generator frequency determined from
pickup
Hz × 256
21
Unit speed from pickup min
-1
22
Generator current in L1 A × 10
IGNEXPO
23
Generator current in L2 A × 10
IGNEXPO
24
Generator current in L3 A × 10
IGNEXPO
25
Actual generator reactive power var × 10
PNTEXPO
positive = inductive
26
Generator power factor
Example: 0064H PF = 1.00
0063H PF = i 0.99 (inductive)
FF9EH PF = c0.98 (capacitive)
27
Current reserve power in the system kW
28
Current actual active power in the system kW
29
Number of subscribers in the CAN bus
30
H.B. Status Mains
L.B. Status Generator
FFH voltage and frequency applied
00H voltage and frequency not applied
31
H.B. Exponent generator current
L.B. Reserve
IGNEXPO
32
Busbar frequency Hz × 100
33
H.B. Status busbar
L.B. Reserve
FFH voltage and frequency applied
00H voltage and frequency not applied
34
Phase-to-phase mains voltage V
23
V × 10
UNTEXPO
35
Phase-to-phase mains voltage V
31
V × 10
UNTEXPO
36
Mains voltage Star V
1N
V × 10
UNTEXPO
37
Mains voltage Star V
2N
V × 10
UNTEXPO
38
Mains voltage Star V
3N
V × 10
UNTEXPO
39
Mains frequency from V
N12
/V
N23
/V
N31
Hz × 100
40
Mains current in L1 A × 10
INTEXPO
41
Mains reactive power var × 10
PNTEXPO
42
Mains power factor
Example: 0064H PF = 1.00
0063H PF = i 0.99 (inductive)
FF9EH PF = c0.98 (capacitive)
43
H.B. Exponent mains power
L.B. Exponent mains voltage
PNTEXPO
UNTEXPO
44
H.B. Exponent mains current
L.B. Reserve
INTEXPO
45
Genset running hours ( H.W.)
h
Double word
46
Genset running hours ( L.W.)
47
Hours until next maintenance h
48
Unit start number
49
Operating mode ( H.B.)
Bit 15 = 1
Internal
Bit 14 = 1
Operating mode STOP
Bit 13 = 1
Operating mode TEST
Bit 12 = 1
Operating mode MANUAL
Bit 11 = 1
Operating mode AUTOMATIC
Bit 10 = 1
Internal
Bit 9 = 1
Internal
Bit 8 = 1
Internal
Operating mode ( L.B.)
Bit 7 = 1 \
Bit 6 = 0 /
Emergency power is ON
Bit 5 = 1 \
Bit 4 = 1 /
Delayed motor monitoring is ON
Bit 3 = 1 \
Bit 2 = 1 /
Coasting END
Bit 1 = 1 \
Bit 0 = 1 /
Internal
