Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 178/190 © Woodward
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
E
MERGENCY POWER CONFIGURATION
Configure emerg.run
YES/NO NO  Y  N  Y  N 2
Emergency power
ON/OFF OFF  on  off  on  off 2
Emergency power start delay
0.5 to 99.9 s 3.0 s 2
Mains settling time
0 to 999 s 10 s 2
CONFIGURATION OF THE PROTECTIVE UNITS
Configure monitoring
YES/NO YES  Y  N  Y  N 2
Gen.power monit.
ON/OFF OFF  on  off  on  off 2
Power monitoring resp.value
0 to 150 % 120 % 2
Power monitoring gen.hyst.
0 to 100 % 5 % 2
power monit. gen. Delay time
0 to 999 s 10 s 2
mains power mon.
ON/OFF OFF  on  off  on  off 2
mains power mon. value
C/E 0 to 9,999 kW 100 kW 2
mains power mon. hyst.
0 to 999 kW 10 kW 2
mains power mon. Delay time
0 to 999 s 1 s 2
Overload monit.
ON/OFF OFF  on  off  on  off 2
Gen.overload MOP resp.value
80 to 150 % 120 % 2
Gen.overload MOP delay
0 to 99 s 12 s 2
Synchr.
Gen.overload IOP resp.value
80 to 150 % 120 % 2
Synchr.
Gen.overload IOP delay
0 to 99 s 15 s 2
Rev./red.power monitoring
ON/OFF ON  on  off  on  off 2
Rev./red.power resp.value
-99 to 0 to +99 % -10 % 2
Rev./red.power delay
0.0 to 9.9 s 3.5 s 2
Load unbalanced monitoring
ON/OFF OFF  on  off  on  off 2
Load unbalanced max.
0 to 100 % 30 % 2
Load unbalanced delay
0.02 to 99.98 s 5.00 s 2
Gen.overcurrent monitoring
ON/OFF ON  on  off  on  off 2
Gen.overcurrent limit 1
0 to 300 % 120 % 2
Gen.overcurrent delay 1
0.02 to 99.98 s 0.20 s 2
Gen.overcurrent limit 2
0 to 300 % 150 % 2
Gen.overcurrent delay 2
0.02 to 99.98 s 0.04 s 2
Gen.frequency- Monitoring
ON/OFF ON  on  off  on  off 2
Gen. overfreq. f >
40.0 to 85.0 Hz 55.00 Hz 2
Gen. overfreq. delay
0.02 to 9.98 s 0.30 s 2
Gen. underfreq. f <
40.0 to 85.0 Hz 45.00 Hz 2
Gen. underfreq. delay
0.02 to 9.98 s 0.30 s 2
Motor over speed >
0 to 9,999 rpm 1,900 rpm 2
Gen.voltage- Monitoring
ON/OFF ON  on  off  on  off 2
Gen.overvoltage U >
70 to 130
10 to 520 V
440 V 2
Gen.overvoltage delay
0.02 to 9.98 s 0.30 s 2
Gen.undervoltage U <
70 to 130
10 to 520 V
360 V 2
Gen.undervoltage Delay time
0.2 to 9.98 s 0.30 s 2
Mains frequency Monitoring
ON/OFF ON  on  off  on  off 2
Mains overfreq. f >
40.0 to 70.0 Hz 50.30 Hz 2
Mains overfreq. Delay time
0.02 to 9.98 s 0.06 s 2
Mains underfreq. f <
40.0 to 70.0 Hz 49.70 Hz 2
Mains underfreq. Delay time
0.02 to 9.98 s 0.06 s 2
