Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 179/190
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
C
ONFIGURATION OF THE PROTECTIVE UNITS
≥V1.0700
Mains volt.monit.
phase-phase
phase-neutral
phase-phase  pp  pn  pp  pn 2
Mains voltage Monitoring
ON/OFF ON  on  off  on  off 2
<V1.070
0
Mains overvolt. U >
20 to 130
20 to 520 V
440 V 2
≥V1.0700
Mains overvolt. U Ph.-Ph. >
20 to 520 V 440 V 2
≥V1.0700
Mains overvolt. U Ph.-N. >
20 to 300 V 254 2
Mains overvolt. Delay time
0.02 to 9.98 s 0.06 s 2
Mains undervolt. U <
20 to 130
20 to 520 V
360 V 2
≥V1.0700
Mains undervolt. U Ph.-Ph. <
20 to 520 V 360 V 2
≥V1.0700
Mains undervolt. U Ph.-N. <
20 to 300 V 208 2
Mains undervolt. Delay time
0.02 to 9.98 s 0.06 s 2
Phase shift monitoring
ON/OFF ON  on  off  on  off 2
Monitoring
single-/only three-
phase
only three-phase 2
Phase shifting (One phase)
3 to 30 ° 12 ° 2
Phase shifting (3-phase)
3 to 30 ° 8 ° 2
Batt. undervolt.
U
<
10.0 to 35.0 8.0 V 2
Batt. undervolt. Delay
0 to 99 s 40 s 2
