Manual 37128A GCP-20 Series - Genset Control
Page 180/190 © Woodward
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
C
ONFIGURATION OF DISCRETE INPUTS
Configure dig.inputs
YES/NO NO Y N Y N 2
Dig. input 1234 function
D/E DDDD D E D E 2
Dig. input 1234 Delay
0 to 9 0000 2
Delayed by 1234 eng.speed
Y/N NNNN Y N Y N 2
Dig. input 1234 Failclass
0 to 3 3210 2
Dig. input 5678 function
D/E DDDD D E D E 2
Dig. input 5678 Delay
0 to 9 0000 2
Delayed by 5678 eng.speed
Y/N NNNN Y N Y N 2
Dig. input 5678 Failclass
0 to 3 1111 2
Dig. input 9ABC function
D/E DDDD D E D E 2
Dig. input 9ABC Delay
0 to 9 0000 2
Delayed by 9ABC eng.speed
Y/N NNNN Y N Y N 2
Dig. input 9ABC Failclass
0 to 3 1111 2
Dig. input DEFG function
D/E DDDD D E D E 2
Dig. input DEFG Delay
0 to 9 0000 2
Delayed by DEFG eng.speed
Y/N NNNN Y N Y N 2
Dig. input DEFG Failclass
0 to 3 1111 2
alarmtext ter. 61
Any Terminal 61 2
Firing speed by ter. 62
YES/NO NO 2
alarmtext ter. 62
Any Terminal 62 2
Lock oper. mode via ter. 63
YES/NO NO 2
alarmtext ter. 63
Any Terminal 63 2
Open transition via ter. 64
YES/NO NO 2
alarmtext ter. 64
Any Terminal 64 2
alarmtext ter. 65
Any Terminal 65 2
alarmtext ter. 66
Any Terminal 66 2
Close GCB asap via ter. 67
YES/NO NO 2
alarmtext ter. 67
Any Terminal 67 2
Emergency Off via ter. 68
YES/NO NO 2
alarmtext ter. 68
Any Terminal 68 2
alarmtext ter. 69
Any Terminal 69 2
alarmtext ter. 70
Any Terminal 70 2
alarmtext ter. 71
Any Terminal 71 2
alarmtext ter. 72
Any Terminal 72 2
alarmtext ter. 73
Any Terminal 73 2
alarmtext ter. 74
Any Terminal 74 2
Function term. 6:
sprinkler operation
engine release
ext.acknowledgement
engine blocking
Start without CB.
Ext. acknowledg. sprinkl.
eng. rel.
ext. ackn.
eng. bl.
st. woCB
sprinkl.
eng. rel.
ext. ackn.
eng. bl.
st. woCB
2
