Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
Page 182/190 © Woodward
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
C
ONFIGURATION OF ANALOG INPUTS
T4-2
Analog input 2 VDO Press.
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
Pressure in bar
bar/psi bar  bar  psi  bar  psi 2
..
analog input 2 VDO
0-5/0-10 bar 0-5 bar  5  10  5  10 2
..
Limit warning value
0.0 to 10.0 bar 2.0 bar 2
..
Limit shutdown value
0.0 to 10.0 bar 1.0 bar 2
..
Analog input 2 VDO
0-73/0-145 psi 0-73 psi  73  145  73  145 2
..
Limit warning value
0.0 to 145.0 psi 8.0 psi 2
..
Limit shutdown value
0.0 to 145.0 psi 9.0 psi 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog input 2 scalable
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
analog input 2
0-20mA/4-20mA 4-20 mA 2
..
value at 0 %
-9,999 to 0 to 9,999 0 2
..
value at 100 %
-9,999 to 0 to 9,999 100 2
..
limit warning value
-9,999 to 0 to 9,999 80 2
..
limit shutdown value
-9,999 to 0 to 9,999 90 2
..
Delay limit 1/2
0 to 999 s 1 s 2
T4-2
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
T4-3
Temperature 3 Pt100/Pt1000
ON/OFF ON  on  off  on  off 2
..
***name****
Any 2
..
limit warning
0 to 255 °C 80 °C 2
..
limit shutdown
0 to 255 °C 90 °C 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog. input 3 PTC
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
limit warning value
0 to 100 % 0 % 2
..
limit shutdown value
0 to 100 % 100 % 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog. input 3 VDO Temp.
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
limit warning
0 to 150 °C 80 °C 2
..
limit shutdown
0 to 150 °C 90 °C 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog input 3 VDO Press.
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
Pressure in bar
bar/psi bar  bar  psi  bar  psi 2
..
analog input 3 VDO
0-5/0-10 bar 0-5 bar  5  10  5  10 2
..
Limit warning value
0.0 to 10.0 bar 2.0 bar 2
..
Limit shutdown value
0.0 to 10.0 bar 1.0 bar 2
..
Analog input 3 VDO
0-73/0-145 psi 0-73 psi  73  145  73  145 2
..
Limit warning value
0.0 to 145.0 psi 8.0 psi 2
..
Limit shutdown value
0.0 to 145.0 psi 9.0 psi 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog input 3 scalable
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
analog input 3
0-20mA/4-20mA 4-20 mA 2
..
value at 0 %
-9,999 to 0 to 9,999 0 2
..
value at 100 %
-9,999 to 0 to 9,999 100 2
..
limit warning value
-9,999 to 0 to 9,999 80 2
..
limit shutdown value
-9,999 to 0 to 9,999 90 2
..
Delay limit 1/2
0 to 999 s 1 s 2
T4-3
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
