Woodward GCP-20 Series User Manual

Manual 37128A GCP-20 Series - Genset Control
© Woodward Page 183/190
Option
Parameter
1. Line Text 2. Line
Adjustment range Standard setting Customer settings
Code
level
C
ONFIGURATION OF ANALOG INPUTS
T4-4
Temperature 4 Pt100/Pt1000
ON/OFF ON  on  off  on  off 2
..
***name****
Any 2
..
limit warning
0 to 255 °C 80 °C 2
..
limit shutdown
0 to 255 °C 90 °C 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog. input 4 PTC
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
limit warning value
0 to 100 % 0 % 2
..
limit shutdown value
0 to 100 % 100 % 2
..
Delay
l
imit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog. input 4 VDO Temp.
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
limit warning
0 to 150 °C 80 °C 2
..
limit shutdown
0 to 150 °C 90 °C 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog input 4 VDO Press.
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
Pressure in bar
bar/psi bar  bar  psi  bar  psi 2
..
analog input 4 VDO
0-5/0-10 bar 0-5 bar  5  10  5  10 2
..
Limit warning value
0.0 to 10.0 bar 2.0 bar 2
..
Limit shutdown value
0.0 to 10.0 bar 1.0 bar 2
..
Analog input 4 VDO
0-73/0-145 psi 0-73 psi  73  145  73  145 2
..
Limit warning value
0.0 to 145.0 psi 8.0 psi 2
..
Limit shutdown value
0.0 to 145.0 psi 9.0 psi 2
..
Delay limit 1/2
0 to 999 s 1 s 2
..
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
..
Analog input 4 scalable
ON/OFF ON  on  off  on  off 2
..
Name and unit
Any 2
..
analog input 4
0-20mA/4-20mA 4-20 mA 2
..
value at 0 %
-9,999 to 0 to 9,999 0 2
..
value at 100 %
-9,999 to 0 to 9,999 100 2
..
limit warning value
-9,999 to 0 to 9,999 80 2
..
limit shutdown value
-9,999 to 0 to 9,999 90 2
..
Delay limit 1/2
0 to 999 s 1 s 2
T4-4
Monitoring for
high/low limit monit. high limit monit.  h  l  h  l 2
T4
Ana input 1234 Superv.del.
Y/N YYYY 2
T4
Ana input 567 Superv.del.
Y/N YYY 2
CONFIGURATION OF THE ANALOG OUTPUTS
A2 Configure outputs?
YES/NO NO  Y  N  Y  N 2
..
Anal.out 120121 Parameter
0 to 22 1 2
..
Anal.out 120121 0-00mA
0-20mA/4-20mA 0-20 mA 2
..
Anal.out 120121 0 %
0 to 9,990 0 2
..
Anal.out 120121 100 %
0 to 9,990 200 2
..
Anal.out 122123 Parameter
0 to 22 1 2
..
Anal.out 122123 0-00 mA
0-20mA/4-20mA 0-20 mA 2
..
Anal.out 122123 0 %
0 to 9,990 0 2
A2
Anal.out 122123 100 %
0 to 9,990 200 2
Assignm. relay 1
According to list 1 2
Assignm. relay 2
According to list 2 2
Assignm. relay 3
According to list 82 2
Assignm. relay 4
According to list 83 2
