03/2003
4-28
8850/ 510DP
REP 8.1
Repairs and Adjustments
3. (Figure 6): Reconnect P/J A28J1 on the left side of the Lower Sheet Feed Assembly.
Figure 6 Reconnecting P/J A28J1
4. Reinstall the Xerographic Module. Perform REP 8.1 Xerographic Module.
5. Close the Printer Top Cover.
6. Return the Printer to normal operation.
P/J A28J1
