Xerox 8850 Service Manual

03/2003
4-89
8850/ 510DP
REP 9.13
Repairs and Adjustments
Replacement
CAUTION
Ensure that the full length of the edge of the Sump Shield is under the edge of the housing.
1. (Figure 2): Reinstall the Sump Shield on the Developer Module.
Figure 2 Reinstalling the Sump Shield in the Developer Module
1
Reinstall the Sump
Shield
2
Reinstall the Sump Shield under
the edges on the housing
