03/2003
7-75
8850/ 510DP
Plug/Jack List
Wiring Data
AC Power Module (A1) Exterior
Figure 1 AC Module (A1)
P/J 9 (Not visible
in photograph)
P/J 8 P/J7 P/J 3A1A2P/J5
A1P5
