03/2003
7-80
8850/ 510DP
Plug/Jack List
Wiring Data
Roll Feed (A7), Rear Lower Frame Assembly (A0)
Figure 6 Rear Lower Frame Assembly Media Roll Drives
A0L3P1/J1
A0L5P1/J1
A0Q4P1/J1
A0L2P1/J1
A0L4P1/J1
A0Q5P1/J1
A0Q6P1/J1
A0L6P1/J1
A0L1P1/J1
A7P1/J1
A7P2/J2
A9P2/J2
A9P1/J1
A24P1/J1
A24P2/J2
