03/2003
7-82
8850/ 510DP
Plug/Jack List
Wiring Data
Fuser and Developer Drive (A20) and Vacuum Transport Fan (A0)
Figure 8 Fuser/Developer Drives and Vacuum Transport Fan
A20M2P1 J1 (on
PWB)
A20M1P1/J1
A0B1P1/J1
Front Door Inter-
lock Switch
A0P/J3A
A0P/J1A
A0P/J2A
