03/2003
7-84
8850/ 510DP
Plug/Jack List
Wiring Data
Media Transport (A21)
Figure 10 Media Transport
A21Q1P1/J1
DETACK
BIAS TRANSFER
ROLL
MEDIA REGISTRATION
SENSOR
