03/2003
7-87
8850/ 510DP
Plug/Jack List
Wiring Data
Drum Drive Motor (A23) and ESV (A29)
Figure 13 Drum Drive Motor and ESV
A23M3P1/J1
A23Q2P1/J1
A31P1/J1
A20P2/J2
