ColorQube 8570/8870 Service Manual
Acronyms and Abbreviations
Introduction
Xerox Internal Use Only - Revised, 3rd Revision
PJL Printer Job Language
PL Parts List
P/N Part Number
PO Part of (Assembly Name)
POP3 Post Office Protocol version 3
POPO Power Off/ Power On
POST Power On Self Test
PPD PostScript Printer Description
PPM Pages Per Minute
PPS Pages
PQ Print Quality
PS PostScript
PVM Print Volume Management
PWB Printed Wiring Board
PWBA Printed Wiring Board Assembly
PWS Portable Work Station
PZT Piezo-Electric Transducer
RAM Random Access Memory
RAP Repair Analysis Procedure for diagnosis of machine status codes and abnor-
mal conditions.
RE Reservoir
REF Refer to
REP Repair Procedure for disassembly and reassembly of component on the
printer.
RET Retard
RGB Three primary colors of light - Red Green Blue
RH Relative Humidity
RJ Right Jetstack
RLS Release
RMS Root-Mean Square
ROM Read-Only Memory
RTD Retard
SCP Service Call Procedure
SCSI Small Computer Systems Interface
SEC Second
SEF Short Edge Feed
Self-Test An automatic process that is used to check Control Logic circuitry. Any fault
that is detected during self-test is displayed by fault code or by LEDs on PWB.
SIMM Single Inline Memory Module used to increase printing capacity.
Simplex Single sided copies
Table 1 Acronyms and Abbreviations
Acronyms/
Abbreviations
Description
SKU Stock Keeping Unit
SLP Service Location Protocol
SMTP Simple Mail Transfer Protocol
SNMP Simple Network Management Protocol
SNR Sensor
SOL Solenoid
sRGB A standard RGB color space created cooperatively by HP and Microsoft in for
use on monitors, printers, and the Internet.
SSDP Simple Service Discovery Protocol
SW or S/W Software
SWOP Specifications for Web Offset Publications
T/A Takeaway
TAR Takeaway Roller
TCP/IP Transmission Control Protocol/ Internet Protocol
TE Trailing Edge
TFTP Trivial File Transfer Protocol
TIFF Tagged Image File Format
TP Test Point
UI User Interface
UL Underwriters Laboratories
UM Unscheduled Maintenance
UP Usage Profile
USB Universal Serial Bus
UV Ultraviolet
VAC Volts Alternating Current
VDC Volts of Direct Current
VGA Video Graphics Array
VPP The waveform is a voltage waveform or Peak to Peak Voltage. Difference
between a waveform's positive peak value and its negative peak value.
VSS Negative Supply
W Watt
W/ With - indicates machine condition where specified condition is present.
W/O Without - indicates machine condition where specified condition is not
present.
WSD Web Services Description
XE Xerox Europe
ZIF Zero Insertion Force (ZIF connector)
Table 1 Acronyms and Abbreviations
Acronyms/
Abbreviations
Description
