Error Messages and Codes 3-39
7
At the exit of the Fuser Assembly, manually
move the exit actuator up and down.
Does the Exit Actuator move smoothly?
Go to step 8. Replace the
Fuser Assembly
(page 8-54).
8
Enter Service Diagnostics, and from the
Sensor Tests menu select the Exit
Sensor (Fuser) test.
Does the sensor correctly report its
state when the actuator is manually
operated?
Replace the
HVPS/Engine
Logic Board
(page 8-89).
Go to step 9.
9
Measure the voltage across P/J46-5 <=>
P/J46-4 while manually operating the Exit
Actuator.
Does the voltage measure 0VDC when
the Exit Actuator is pushed, and 3.3
VDC when released?
Replace the LVPS
(page 8-78).
Go to step 10.
10
1. Disconnect P/J46 from the LVPS.
Warning: Allow the Fuser Assembly to
cool before removing.
2. Remove the Fuser Assembly
(page 8-54).
3. Check the Fuser Harness for continuity
Is P/J46 <=> P/J4647 continuous?
Go to step 11. Replace the
Fuser Harness
Assembly
(page 8-50).
11
Check the power to the Exit Sensor:
Measure the voltage across P/J46-3 <=>
P/J46-4.
Is the voltage 3.3 VDC?
Go to step 13. Go to step 12.
12
Check the LVPS for continuity between
P/J41-1 and P/J 46-3.
Is it continuous?
Go to “LVPS (Low
Voltage Power
Supply)” on
page 4-4.
Replace the
LVPS (page 8-78)
13
Warning: Allow the Fuser Assembly to
cool down before removing.
1. Remove the Fuser Assembly
(page 8-54).
2. Manually turn the Fuser Assembly’s
heater roller gear.
Do the gear and the roller of the Fuser
Assembly rotate smoothly?
Replace the
HVPS/Engine
Logic Board
(page 8-89).
Replace the
Fuser Assembly
(page 8-54)
14
1. Remove the Transfer Roller Assembly
(page 8-55).
2. Inspect the Transfer Roller Assembly for
shape irregularities and shaft and
bearing wear.
Are there any abnormalities in Transfer
Roller Assembly?
Replace the
Transfer Roller
Assembly
(page 8-55).
Go to step 15.
Troubleshooting Procedure (Continued)
Steps Actions and Questions Yes No
To Next Page
