FRU Disassembly 8-15
Print Engine: 150- or 550-Sheet Paper
Cassette
Retard Roller and Holder
(PL2.1.2 and 2.1.51 for 150-sheet, PL 4.1.2 and 4.1.51 for 550-sheet); the roller is
also part of the Maintenance Kit.
1. Retard Roller 2. Retard Holder
s4500-064
2
1
