8-58 Phaser 4500 Service Manual
Print Cartridge Right Guide Assembly
(PL8.1.25)
1. Image Processor Shield Assembly 3. HVPS/Engine Logic Board
2. HVPS Shield Plate 4. Print Cartridge Right Guide Assembly
S4500-124
