10-10 Phaser 4500 Service Manual
550-Sheet Feeder Plug/Jack Locator
P/J Locator Table
P/J Coordinates Remarks
80 I-205 Connects Feeder Size Switch Harness 2 and the 550-Sheet Feeder
PWBA
81 H-205 Connects the Low Paper Sensor Harness and the 550-Sheet Feeder
PWBA
82 H-205 Connects the Feeder Motor Harness and the 550-Sheet Feeder PWBA
83 I-205 Connects Feeder Harness 2 and the 550-Sheet Feeder PWBA
84 I-205 Connects Feeder Harness 5 and the 550-Sheet Feeder PWBA
85 H-205 Connects Clutch/Sensor Harness 2 and the 550-Sheet Feeder PWBA
801 H-203 Connects Feeder Size Switch Harness 1 and Feeder Size Switch
Harness 2
802 C-204 Connects Feeder Size Switch Harness 1 and Size Switch Assembly
810 I-205 Connects the Low Paper Sensor and Low Paper Sensor Harness
820 G-203 Connects the Feeder Motor and Feeder Motor Harness
852 I-205 Connects the No Paper Sensor and Clutch/Sensor Harness 1
853 G-203 Connects the Feeder Clutch and Clutch/Sensor Harness 1
854 H-203 Connects the Turn Roller Clutch and Clutch/Sensor Harness 1
855 J-204 Connects Clutch/Sensor Harness 1 and Clutch/Sensor Harness 2
2083 G-205 Connects Feeder Harness 1 and Feeder Harness 2
8483 G-206 Connects Feeder Harness 5 and Feeder Harness 5
