Xerox Phaser 4500 Service Manual

1-4 Phaser 4500 Service Manual
Parts of the Printer
Front View
Rear View
1. Paper stop
2. Front panel
3. Tray 1
4. On/Off switch
5. Tray 2
6. Optional Tray 3
7. Optional Tray 4
8. Paper gauge
9. Print cartridge
10.Standard output tray
11.Optional 500-Sheet Stacker
The Image Processor Board
contains items 1 - 4.
1. Parallel cable connector
2. Ethernet 10/100 Base-T
connector
3. USB connector
4. Configuration card
5. Power receptacle
6. Optional Duplex Unit
7. Rear cover
8. Stacker rear cover
9. Stacker extension
4500-07
2
2
1
11
10
9
4
5
6
7
8
3
4500-073
8
9
6
5
7
1
2
3
4
