Error Messages and Codes 3-53
2
Check Feeder Harness 5 of the Tray 3
Feeder:
1. Remove Optional 550-Sheet Paper
Feeder.
2. Disconnect P/J84 from the 550-Sheet
Feeder PWBA.
3. Check the following for continuity:
■ J84-1 <=> J8483-10
■ J84-2 <=> J8483-9
■ J84-3 <=> J8483-8
■ J84-4 <=> J8483-7
■ J84-5 <=> J8483-6
Is each continuous?
Go to step 3. Replace Feeder
Harness 5.
3
Check Feeder Harness 2 of the Tray 4
Feeder:
1. Remove the Optional 550-Sheet Paper
Feeder.
2. Disconnect P/J8483.
3. Check the following for continuity:
■ J8483-1 <=> J83-10
■ J8483-2 <=> J83-9
■ J8483-3 <=> J83-8
■ J8483-4 <=> J83-7
■ J8483-5 <=> J83-6
Is each continuous?
Go to “Optional
550-Sheet Feeder
PWBA (Tray 4)” on
page 4-44.
Replace Feeder
Harness 2.
Troubleshooting Procedure (Continued)
Steps Actions and Questions Yes No
To Next Page
