4-24 Phaser 4500 Service Manual

Check the Toner Harness Assembly 2:

1. Remove the Toner Harness Assembly 2.

2. Test for continuity across J22 <=> J221.

Is it continuous?

Go to step 7. Replace the

Toner Harness

Assembly 2.

Replace the Toner Sensor (page 8-30).

Does the problem still occur after

replacement?

Replace the

HVPS/Engine

Logic Board

(page 8-89).

Problem solved.

Troubleshooting Procedure (Continued)

Steps Actions and Questions Yes No
