Xerox Phaser 4500 Service Manual

5-38 Phaser 4500 Service Manual
4
Warning: Allow the Fuser Assembly
to cool before removing.
1. Open the Rear Cover and remove
the Fuser Assembly.
2. Manually rotate the Fuser Drive
Gear and inspect the Heat Roller.
3. Open the Fuser Jam Access
cover.
4. Manually rotate the Fuser Drive
Gear and inspect the Pressure
Roller Drive.
Are the Heat Roller and the
Pressure Roller free of surface
defects and contamination?
Go to step 5. Replace the Fuser
Assembly (page 8-54).
5
Replace the following, in order, until
the defective component is found:
■ Transfer Roller Assembly
(page 8-55)
■ Laser Assembly (page 8-46)
Spot Deletions Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
