6-6 Phaser 4500 Service Manual
6. Select a quantity of 5, then press the Back button to enter the selection.
Note
Use the OK button to move the highlight over the digit you want to change.
Use the Up Arrow and Down Arrow buttons to change the value of the
digit.
7. Select Print Test Pattern, then press the OK button to print the Engine Test
Pattern.
8. Check the following measurements on two consecutive test patterns of the five
made from the tray in step 6.
If a registration measurement does not meet the specification, perform the
simplex adjustment procedure on page 6-7.
9. Repeat steps 3 through 8 for each tray.
To test the duplex registration, continue with step 10. You cannot perform the
duplex registration test unless the printer has a duplex unit.
10. From the Engine Test Print menu, select Duplex, then press the OK button.
11. Set Duplex to On, then press the OK button to save the setting.
Note
If Duplex is Off, press the Down Arrow button to change it to On.
12. Repeat steps 7 and 8. Check the registration for the duplexed prints.
If a registration measurement does not meet the specification, perform the duplex
adjustment procedure on page 6-8.
Distance Measurement
From the lead edge of the paper to the first horizontal line
(measurement A in the figure on page 6-4)
4 mm ± 2 mm
From the left edge of the paper to the edge of the thick
vertical line (measurement B in the figure on page 6-4)
4 mm ± 2.5 mm
