Xerox Phaser 4500 Service Manual

Parts Lists 9-7
FRU Parts List 2.1 150-Sheet Paper Cassette
No. Name/Description Part Number
1 COVER CST 802E47191
2 ROLL ASSY RETARD (p/o Item 99)
3 FRICTION CLUTCH
4 SHAFT RETARD
5 HOLDER RETARD
6 SPRING RETARD 809E37500
7 GEAR PB L
8 GEAR BTM ONEWAY
9 SHAFT PB
10 PLATE ASSY BTM (with 14)
11 GUIDE ASSY SD L150
12 GEAR PINION
13 GUIDE ASSY SD R150
15 GEAR LOCK ONEWAY
16 HOUSING TOP 150
17 LOCK EXTENSION
18 SPRING BTM UP 150
19 PLATE GEAR LOCK 150
20 GEAR PB R
21 RACK BTM LOCK 150
22 COVER BTM UP 150
23 GEAR BOTTOM LOCK PINION
24 SPRING BTM LOCK
25 GEAR LEVER LOCK
26 LEVER BTM LOCK
27 SPRING STOPPER GEAR
28 STOPPER GEAR
29 PLATE SUPPORT
30 COVER EXTENSION
31 GEAR SECTOR
32 RACK SIZE
33 HANDLE EXTENSION 150
