9-16 Phaser 4500 Service Manual
FRU Parts List 7.1 550-Sheet Paper Feeder
No. Name/Description Part Number
1—
2 HARNESS ASSY LOW1 (J26-P260)
3 GUIDE TRAY RIGHT 032E18795
4 SENSOR LOW PAPER (J260) 130E81970
5 ACTUATOR 120E21311
6 PLATE CST LOCK
7 GUIDE TRAY LEFT (with 8,9) 032K96836
8 COVER HARNESS SIZE
9 LOCK CST L 003E59231
10 550 FEEDER ASSY (with 12-20, 22-31, 33-39) 022K66964
12 SUPPORT NUDGER
13 HOLDER LEFT
14 ACTUATOR NO PAPER
15 GEAR IDLER NUDGER
16 HOLDER RIGHT
17 SHAFT NUDGER
18 GEAR NUDGER 059K25270
19 ROLL ASSY NUDGER (part of item 99)
20 CLUTCH ASSY PH (J247) 121K28511
22 BEARING NUDGER
23 COVER ACTUATOR
24 CHUTE BTM
25 CHUTE TOP ASSY
26 SHAFT FEED
27 CLUTCH ONEWAY NUDGER 005E16951
28 CLUTCH ONEWAY FEED 005E16941
29 ROLL ASSY FEED (Part of item 99)
30 HOLDER PIVOT LEFT
31 EARTH PLATE
32 CHUTE 550 LOWER
33 CHUTE OUT
34 HOLDER PIVOT RIGHT
To Next Page
