Parts Lists 9-19
FRU Parts List 8.1 Xerographics
No. Name/Description Part Number
1 ROS ASSY (Laser Unit) (J131,J140,J160,J170) 084K13151
2 HARNESS ASSY ROS (J13, J14, J16, J17-P131, P140, P141, P160,
P170)
3 SHIELD PLATE ROS
4 DUCT FRONT
5 FAN SUB (J270) 127K39390
6 GUIDE ASSY CRU L (with 7-15) 032K97110
7 GUIDE SL (part of item 6)
8 SPACER SS (part of item 6)
9 SPRING SL (part of item 6)
10 HOLDER I/L SW1 (part of item 6)
11 INTERLOCK S/W 24 V (J45) (part of item 6)
12 INTERLOCK S/W 5 V (part of item 6)
13 HOLDER I/L SW2 (part of item 6)
14 LEVER GUIDE (Guide Lever) (part of item 6)
15 GUIDE CRU LEFT (part of item 6)
16 COVER GUIDE CRU
17 HARNESS ASSY FUSER 110V (J4647-J46, J47) 962K08241
HARNESS ASSY FUSER 220V (J4647-J46, J47) 962K12941
18 LEVER FUSER LH 011E13362
19 LEVER FUSER RH 011E13373
20 FUSER ASSY 110V 604K14921
FUSER ASSY 220V 604K14931
21 BTR ASSY (Transfer Roller Assembly) 802K49746
22 CHUTE TRANSFER 054E26070
23 PWBA ASSY ANT (P150) (part of item 25)
24 HARNESS ASSY ANT (J15-J150) (part of item 25)
25 GUIDE ASSY CRU R (J31) (with 23, 24) 032K97011
29 LEVER LINK 012K94351
30 LINK GEAR 3 012E10561
To Next Page
