Parts Lists 9-21
FRU Parts List 10.1 Paper Exit (1/2)
No. Name/Description Part Number
1 COVER EXIT 500 604K16590
2 500 EXIT ASSY (with 4-7, 10-13, 15-24, 26-28, 30) 084K18470
4 CHUTE UP EXIT
5 ELIMINATOR EXIT
6 EARTH PLATE EXIT
7 LINK GATE OCT (Stacker Gate Link)
10 ACTUATOR FULL STACK 604K15560
11 BEARING EXIT
12 ROLL EXIT
13 GEAR 21
15 MOTOR ASSY EXIT (J103) 127K36930
16 BRACKET MOTOR EXIT
17 GEAR 16/49
18 GEAR 25-2
19 GEAR 25-1
20 GATE OCT EXIT (Stacker Exit Gate)
21 CHUTE LOW EXIT
22 SPRING PINCH EXIT
23 ROLLER PINCH EXIT
24 SPRING GATE OCT (Stacker Gate Spring)
26 SENSOR FULL STACK (P290) 130E81970
27 HARNESS ASSY EXIT SNR (J29-J290)
28 ROLLER EXIT 500
30 ROLL PINCH EXIT OCT (Stacker Exit Pinch Roller)
To Next Page
