9-30 Phaser 4500 Service Manual
Parts List 20.1 550-Sheet Paper Feeder (1/2)
No. Name/Description Part Number
1COVER RIGHT PLATE
2COVER FRONT
3 COVER LEFT PLATE
4 EARTH PLATE
5 HARNESS ASSY FDR2 (J83-JD2083) (Feeder Harness 2)
6 SPRING EARTH TOP
7 FRAME TOP ASSY
8 DRIVE ASSY OPT FDR (with 9-17) 007K87654
9 BRACKET ASSY DRIVE
10 GEAR OPT FDR2
11 GEAR OPT FDR3
12 GEAR OPT FDR4
13 GEAR OPT FDR5
14 GEAR OPT FDR6
15 PLATE FEEDER DRIVE
16 CLAMP-5 V0
17 MOTOR FEEDER (J820)
18 OPT ASSY SIZE (J802) (Paper Size Switch Assembly) 110K11634
19 HARNESS ASSY SIZE FDR1 (P802-J801)
20 PLATE EARTH 550
21 FRAME CVR L550
22 FOOT
23 FRAME BASE FRONT
25 COVER RE550
26 HARNESS ASSY FDR5 (J84-PD8483) (Feeder Harness 5)
27 PLATE CST LOCK
28 FRAME CVR R550
29 HLD LOW PAPER ASSY (P810) (with 30-33) 019K98503
30 SENSOR LOW PAPER (P810)
31 ACTUATOR LOW PAPER
32 HOLDER LOW PAPER
33 HARNESS LOW PAPER (J81-J810)
To Next Page
