Parts Lists 9-33
Parts List 20.2 550-Sheet Paper Feeder (2/2)
No. Name/Description Part Number
1 550 FEEDER OPTION (with 4-23, 25-34) 022K66124
4 SUPPORT NUDGER
5 HOLDER LEFT
6 ACTUATOR NO PAPER
7 GEAR IDLER NUDGER
8 HOLDER RIGHT
9 SHAFT NUDGER
10 GEAR NUDGER 059K25270
11 ROLL ASSY NUDGER (part of 99)
12 ROLL ASSY FEED (part of 99)
13 CLUTCH ONEWAY FEED 005E16941
14 ROLL ASSY TURN
15 CLUTCH ONEWAY NUDGER 005E16951
16 SHAFT FEED
17 BEARING NUDGER 013E22571
18 CHUTE TOP ASSY
19 COVER ACTUATOR
20 CHUTE BTM
21 CLUTCH ASSY PH (J853) (Feed Clutch) 121K28511
22 CLUTCH PR-REGI (J854) (Turn Roller Clutch) 121K28511
23 BEARING FEEDER
25 CHUTE OUT
26 SPRING EARTH (Ground Spring)
27 SPRING PINCH TURN
28 ROLL PINCH TURN
29 PLATE TIE
30 CLAMP-5 V0
31 HARNESS ASSY CLSNR1 (J855-J852, P853, P854)
32 COVER HARNESS R
33 SENSOR NO PAPER (P852) 130E81970
34 CHUTE 550 LOWER
99 Roller Kit (with 11 or 12, qty. 3) 604K11192
To Next Page
