9-42 Phaser 4500 Service Manual
35 CHUTE OFFSET ASSY (with 13, 36-39) 054K23313
36 ROLL OCT UPPER (Upper Stacker Roller)
37 ROLL PINCH OCT (Stacker Pinch Roller)
38 CHUTE OFFSET
39 SPRING PINCH EXIT
40 TRAY ASSY OCT (with41-44, 53) (Stacker Tray Assembly) 050K49264
41 TRAY EXTENSION
42 TRAY EXIT
43 TRAY BASE
44 SPRING TRAY
45 COVER FRONT
46 HARNESS ASSY OCT MOT (J71-P710) (Stacker Motor Harness)
47 LINK
48 SHAFT FULL STACK 006E79380
49 FLAPPER ASSY L (with 47) 036K91582
50 FLAPPER ASSY R (with 47) 036K91592
51 SPRING
52 DAMPER ASSY TRAY L 004K02070
53 STOPPER
54 DAMPER ASSY TRAY R 004K02080
99 STACKER ASSY (ENTIRE UNIT) 084K18114
Parts List 23.1 Stacker (Continued)
No. Name/Description Part Number
To Next Page
