Error Messages and Codes 3-7
On the Front Panel, the Jam History lists a series of entries separated by semi-colons.
Each entry is made up of two values separated by a comma: the first value is the
numeric Fault History Code for the Jam Location, and the second value is the engine
page count. An entry of 5,132 would mean that a Jam at Exit occurred at page count
132.
Fault History Codes for Jams
Fault
History
Code
Service Usage Profile Log Reports
Last Jam Location (Item 291) Jam Code (Item 298)
1 Jam at Tray 1 E2-01, E2-02, E2-11
2 Jam at Tray 2 E2-02, E2-12
3 Jam at Tray 3 E2-03, E2-13
4 Jam at Tray 4 E2-04, E2-14
5 Jam at Exit E4-0, E4-2, E4-3
6 Jam at Top E3-1, E3-2
7 Jam at Duplex E7-0, E7-1, E7-2, E7-3
8 Jam at Rear E6-1
9 Jam at Stacker E6-2
10 Paper Size Jam PSE-1
