Xerox PHASER 6130 Service Manual

3-48 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
9 Check the Regi. Sensor (Photo
Sensor) for operation.
Perform the Regi Sensor test: Service
Mode > Engine Diag > Sensor Test >
Regi Sensor
Does the number on the screen
increase by one, when the actuator
(Regi In Actuator) is operated?
Go to step 10. Go to step 13.
10 Check the Main Motor (Main Drive
Assembly) for operation. During this
check, defeat the Front Cover interlock
switch (HARN ASSY INTERLOCK).
Perform the Main Motor test
(page 4-27): Service Mode > Engine
Diag > Motor Test > Main Motor.
Does the Motor operate properly?
Go to step 11. Go to step 20.
11 Check the Regi. Clutch (CLUTCH ASSY
DRV) for operation, and Regi Roll Assy
and Metal Regi Roll for rotation
First, start the Main Motor FULL2 test:
Service Mode> Engine Diag > Motor
Test > Main Motor FULL2, then start
the Regi Clutch test: Service Mode >
Engine Diag > Motor Test > Regi
Clutch.
Does the Regi. Clutch operate
properly, and do the Regi Roll Assy
and Metal Regi Roll rotate?
During this check, defeat the Front
Cover interlock switch (HARN ASSY
INTERLOCK).
Go to step 12. Go to step 17.
12 Reseat the connectors on the Transfer
Unit.
Does the error still occur when
printing?
Replace the
Transfer Unit.
(page 8-41)
Complete
13 Check the connectors of the Regi
Sensor (Photo Sensor) for connection
Check the connections between the
MCU Board and Regi Sensor (Photo
Sensor).
Are P/J23 and P/J232 connected
correctly?
Go to step 14. Reconnect the
connector(s) P/
J23 and/or P/
J232 correctly.
14 Check the Left Side Harness Assy for
continuity
Disconnect J23 from the MCU Board.
Disconnect J232 from the Photo
Sensor.
Is each cable of J23 <=> J232
continuous?
Go to step 15. Replace the
Feeder Assy
(page 8-25) or
Left Side
Harness Assy
(page 8-26).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
