Xerox PHASER 6130 Service Manual

Phaser 6130 Color Laser Printer Service Manual 5-23
Print-Quality Troubleshooting
4 Check the Advanced tab of the Printer
Driver.
Is the Draft Mode selected?
Cancel the Draft
Mode, then go
to step 5.
Go to step 6.
5 Is the image printed correctly? Complete Go to step6.
6 Perform the Toner Pallet Check:
Service Mode > Test Print> Toner
Pallet Check
Is one or more of the colors faint?
Go to step 7. Check the
original printing
data.
7 Reseat the Toner Cartridges, and
check that their lock keys are in the
lock positions.
Is the image printed correctly?
Complete Go to step 8.
8 Open the Front Cover and check the
Transfer Unit HV connections.
Are the four HV contacts on the right
side of the Transfer Unit, and four
springs on the frame (PL4.1.11, 12,
13, 14) dirty and/or deformed?
Clean or replace
the Transfer Unit
or spring(s),
then go to step
9.
Go to step 9.
9 Remove the Imaging Unit and check
the Imaging Unit HV connections
Are the five HV terminals on the
Imaging Unit, and five springs on the
frame (PL4.1.10 and PL4.1.15 to 18)
dirty and/or deformed?
Clean and/or
replace the
Imaging Unit or
spring(s), then
go to step 10.
Go to step 10.
10 Reseat the Imaging Unit.
Is the image printed correctly?
Complete Go to step 11.
11 Check the laser beam windows of the
Laser Unit
Are the laser beam windows on the
Laser Unit clean?
Go to step 12. Clean the
window(s) with
soft cloth or
cotton swab
gently.
12 Check the laser beam path
Are there any foreign substances
between the Laser Unit and Imaging
Unit?
Remove the
foreign
substances.
Go to step 13.
13 Perform the Toner Motor test for each
color: Service Mode > Engine Diag >
Motor Test > Yellow/Magenta/Cyan/
Black Toner Motor
Does the Toner Dispenser Motor
function normally?
Go to step 15. Replace the
Dispenser Assy
(page 8-34),
then go to step
14.
14 Is the image printed correctly? Complete Replace the
MCU Board
(page 8-59).
15 Reseat the connectors on the MCU
Board.
Is the image printed correctly?
Complete Go to step 16.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
