5-24 Phaser 6130 Color Laser Printer Service Manual
Print-Quality Troubleshooting
16 Reseat the connectors on the IP
Board.
Is the image printed correctly?
Complete Go to step 17.
17 Open and close the Front Cover to
reseat the Transfer Unit.
Is the image printed correctly?
Complete Go to step 18.
18 Replace the Transfer Unit (page 8-41)
Is the image printed correctly?
Complete Go to step 19.
19 Replace the Imaging Unit. (page 8-8)
Is the image printed correctly?
Complete Go to step 20.
20 Replace the Dispenser Motor Assy
(page 8-34).
Is the image printed correctly?
Complete Go to step 21.
21 Replace the Laser Unit. (page 8-31)
Is the image printed correctly?
Complete Replace the IP
Board
(page 8-60)
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
