60H5E11
Bracket unit
BRKT
7-29
a
b
3. Remove the gear pump cover and gear
pump.
60h70640
NOTE:
Make sure that the shuttle piston and ball are
removed, since they would be stuck on the gear
pump cover.
4. Remove the up-relief valve assembly.
60h70650
5. Remove the main valves.
60h70660
NOTE:
To remove the main valves, cover the pump
housing with a clean cloth, and blow com-
pressed air through holes A and B.
Never look into the openings while remov-
ing the main valves.
6. Remove the manual valve.
60h70670
To Next Page
