Is measured
voltage exceeds the
specified value?
Measure the CDI unit output
peak voltage.
Replace the CDI
unit.
Check the ignition timing.
Check each component again.
Is ignition
timing correct?
Adjust the ignition timing.
Check the power unit.
Power unit
Measure the compression
pressure.
Does the measured
pressure exceed the
specified value?
Check the cylinder head, cylinder
head gasket, piston, piston rings,
and cylinder block.
Check each component again.
9-8
