Yamaha 200A - Exhaust System Parts

60H5E11
5
1
2
3
4
5
6
7
8
9
10
11
12
13
4
14
15
16
Exhaust
60H50255
1 Bolt 7 M6 x 20mm
2 Cylinder cover 1
3 Gasket 1
4 Gasket 2
5 Exhaust inner cover 1
6 Exhaust outer cover 1
7 Bolt 29 M6 x 35mm
8 Gasket 1
9 Pressure control valve cover 1
10 Bolt 2 M6 x 20mm
11 Pressure control valve seat 1
12 Pressure control valve 1
13 Spring 1
14 Clamp 1
15 Bolt 1 M6 x 12 mm
16 Clamp 1
No. Part name Q’ty Remarks
Intake manifold / Exhaust
5-20
