Yamaha 200A - Intake Manifold Parts

60H5E11
Power unit
POWR
1
2
3
4
5
6
8
4
5
7
12
11
11
9
10
2
3
13
14
15
13
14
15
60H50185
Intake manifold
1 Gasket 1
2 Reed valve 6
3 Gasket 6
4 Clamp 2
5 Bolt 16 M6 x 25mm
6 Bolt 12 M5 x 15mm
7 Hose 3
8 Hose 1
9 Hose 1
10 Hose 1
11 Clamp 2
12 Hose 6
13 Bolt 4 M6 x 20 mm
14 Bushing 2
15 Damper bracket 2
No. Part name Q’ty Remarks
5-17
