60H5E11
SPEC
General Information
Tightening torques
Specified torques
POWER UNIT
Flywheel nut M20 160 16 116
1st
M10
20 2 15
Crankcase bolt
2nd 39 3.9 29
1st
M8
10 1 7
2nd 18 1.8 13
Intake manifold
1st
M6
4 0.4 3
2nd 8 0.8 6
Cylinder head
1st
M8
15 1.5 11
2nd 29 2.9 21
Cylinder head cover 1st
M6
4 0.4 3
Thermostat cover 2nd 8 0.8 6
1st 19 1.9 14
2nd 36 3.6 27
Connecting rod cap 3rd M8 Loosen completely
4th 19 1.9 14
5th 36 3.6 27
Exhaust outer cover
1st
M6
4 0.4 3
2nd 8 0.8 6
PCV cover
1st
M6
4 0.4 3
2nd 8 0.8 6
Cylinder head accessory plug M14 23 2.3 17
Power unit mount bolt M8 21 2.1 15
Spark plug M14 25 2.5 18
Electric relay terminal nut M6 4 0.4 3
Starting motor mount bolt M8 29 2.9 22
Starting motor (+) terminal nut M8 9 0.9 6
Ignition coil M6 8 0.8 6
Battery cable terminal nut
M6 4 0.4 3
M8 6 0.6 5
Hour meter M5 2 0.2 2
LOWER UNIT
Pinion nut M16 93 9.3 69
Propeller nut M18 54 5.4 40
Gear oil plug 9 0.9 6
Ring nut 145 14.5 105
Trim tab M10 39 3.9 29
Lower case mount bolt M10 39 3.9 29
Upper case mount bolt M8 21 2.1 15
Exhaust manifold M8 18 1.8 13
Muffler M8 18 1.8 13
Part to be tightened Thread size
Tightening torques
N • m kgf • m ft • lb
2-9
