Yamaha 200A - Page 31

60H5E11
2
B5
B9
B4
C3
D1
D2
B1
B9
B9
B2
B6
D1
B3
Item Unit
B1
B2
B3
B4
B5
B6
B9
C3
D1
D2
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
125.4 (4.9)
254 (10.0)
163.5 (6.4)
50.8 (2.0)
180 (7.1)
367 (14.5)
18.5 (0.7)
82 (3.2)
13 (0.5)
55.5 (2.2)
Model
200AET L200AET
Clamp bracket
Maintenance specifications
2-8
