Yamaha 200A - Carburetor Parts List

60H5E11
Fuel system
FUEL
60H40130
4-9
1 Gasket 3
2 Nut 12
3 Carburetor 1 1
4 Carburetor 2 1
5 Carburetor 3 1
6 Accelerator lever rod 1
7 Choke rod 2
8 Joint 5
9 Choke nob 1
10 Gasket 3
11 Intake silencer 1
12 Screw 12 M5 x 55 mm
13 Hose 1
14 Bolt 2 M6 x 15 mm
15 Choke solenoid 1
16 O-ring 1
17 Grommet 1
No. Part name Q’ty Remarks
Carburetor
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
