Assembling the carburetor
• Do not apply the excessive force to push-
in the needle valve.
• Do not apply the excessive force to screw-
in the pilot screw.
NOTE:
Install the pilot screw 1, turn-in until it is lightly
seated, and then turn out by the specified num-
ber of turns.
60H40170
Pilot screw 1 turn-out :
1 1/8 ± 1/4 (7/8 - 1 3/8)
