Yamaha 200A - Fuel System

60H5E11
9
Power unit
Ye s
No
Ye s
No
Ye s
No
Ye s
No
Ye s
No
Continued on next page.
Is measured
voltage exceeds the
specified value?
Replace the pulser
coil.
Measure the charge coil output
voltage.
Replace the charge
coil.
Is measured
voltage exceeds the
specified value?
Is measured
voltage exceeds the
specified value?
Measure the CDI unit output
peak voltage.
Replace the CDI
unit.
Check the ignition timing.
Check each component again.
Is ignition
timing correct?
Adjust the ignition timing.
Check the fuel system.
Fuel system
Check that the fuel vent screw
of the fuel tank is open.
Is the vent
screw open?
Open the fuel vent screw.
9-4
