Yamaha 200A - Steering Arm Parts

60H5E11
Bracket unit
BRKT
7-41
60h70035
1 Steering arm 1
2 Washer 1
3 Bushing 2
4 Swivel bracket 1
5 O-ring 1
6 Bushing 1
7 Washer 1
8 Steering yoke 1
9 Circlip 1
10 Nut 2
11 Thrust receiver 2
12 Damper 1
13 Clamp bracket 1 Starboard
14 Clamp bracket 1 Port
No. Part name Q’ty Remarks
Steering arm
1
5
6
7
8
9
2
3
4
3
11
10
13
14
12
