Yamaha 200A - Electrical Specifications

60H5E11
SPEC
General Information
Electrical
Item Unit
Ignition system
Ignition timing
(standard ignition timing)
(full advance)
Piston position
(full advance)
Pulser coil output peak voltage
(W/B - W/L, W/Br - W/Y, W/G - W/R)
at cranking 1(*1)
at cranking 2(*1)
at 1,500 r/min
at 3,500 r/min
Pulser coil resistance(*2)
(W/B - W/L, W/Br - W/Y, W/G - W/R)
Charge coil output peak voltage
(Br - R)
at cranking 1(*1)
at cranking 2(*1)
at 1,500 r/min
at 3,500 r/min
(L - B/R)
at cranking 1(*1)
at cranking 2(*1)
at 1,500 r/min
at 3,500 r/min
Charge coil resistance(*2)
(Br - R)
(L - B/R)
CDI unit output peak voltage
(B/W - B)
at cranking (loaded)
at 1,500 r/min
at 3,500 r/min
Spark plug gap
Ignition spark gap
Spark plug cap resistance
Ignition coil resistance
Primary coil (B/W-B)
Secondary coil (LEAD-B)
Thermoswitch
ON
OFF
Choke solenoid
Resistance
Degree
Degree
mm (in)
V
V
V
V
Ω
V
V
V
V
V
V
V
V
Ω
Ω
V
V
V
mm (in)
mm (in)
Ω
Ω at 20°C (68°F)
Ω at 20°C (68°F)
°C (°F)
°C (°F)
Ω
ATDC 7
BTDC 18
2.05 (0.0807)
2.5
2.0
9.5
16.0
256 - 384
80
90
165
165
30
30
160
165
428 - 642
64.4 - 96.6
65
140
135
1.0 - 1.1 mm (0.039 - 0.043 in)
6 (0.24)
4.0 - 6.0
0.18 - 0.24
3.26 - 4.88
84 - 90 (183 - 194)
60 - 74 (140 - 165)
3.4 - 4.0
(*1) Cranking 1: unloaded Cranking 2: loaded
(*2) The figures are for reference only.
Model
200AET L200AET
2-5
