3. Lubricate:
•
Oil seal lips
•
4. Install:
•C ollars
Recommended
lubricant
Lithium-soap-based grease
• Front wh
ee l
• Wheel axle
5. Tighten:
• Wheel axle
• Wheel axle pinch boll
£CA1RCl401
NOTICE
Wheel axle
65 Nm (6.5 m·kgf, 47 ft ·lbf)
Wheel axle
pinch bolt
23 Nm (2.3 m·kgf, 17 ft ·lbf)
~~~~~~~~~~~~~
Before tightening the wheel axle, push down
hard on
the handlebar several times and
check if the front fork rebounds smoothly.
TIP ~~~~~~~~~~~~~~
Check that wheel ax le end "a" is flush wi th front
fo lk surface "b" and then tighten the wh ee l ax le
p
in ch bolt. If end "a" is not flush wi th surface "b",
align the en ds manually or wi th a plastic ham-
mer.
b
a
6. Install:
• Front brake calipers
Front brake caliper bolt
35 Nm (3.5 m·kgf, 25 ft ·lbf)
EWA l lSOO
A WARNING
Make sure the brake hose is routed properly.
4-13
FRONT WHEEL
