YASKAWA LA500 - Page 231

Specifications
10
10.5 Drive Exterior and Mounting Dimensions
YASKAWA SIEPYEULA5001C LA500 Technical Manual 231
■ 2018 to 2075, 4015 to 4045
Figure 10.3 Exterior and Mounting Dimensions
Three-Phase 200 V Class
Table 10.11 IP20/UL Open Type, without Built-in EMC Filter
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2025A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.4
(7.5)
2033A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.6
(7.9)
2047A
180
(7.09)
300
(11.81)
143
(5.63)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
2060A
220
(8.66)
350
(13.78)
187
(7.36)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
7.5
(16.5)
2075A
220
(8.66)
350
(13.78)
187
(7.36)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
8.0
(17.6)
Table 10.12 IP20/UL Open Type, with Built-in EMC Filter
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2025E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
2033E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
4.1
(9.0)
2047E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
6.0
(13.2)
2060E
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
8.5
(18.7)
2075E
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
9.0
(19.9)
