YASKAWA LA500 - H6: Pulse Train Input;Output

Parameter List
11
11.8 H: Terminal Functions
YASKAWA SIEPYEULA5001C LA500 Technical Manual 255
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H5-17
(11A1)
Expert
ENTER command
response @CPU BUSY
Sets operation when the EEPROM write command is sent without EEPROM write
available. Usually it is not necessary to change this setting.
0 : Ignore Command(No ROM/RAM Write)
1 : Write to RAM Only
0
(0, 1)
324
H5-18
(11A2)
Motor Speed Filter over
Comms
Sets the filter time constant used when monitoring motor speed during MEMOBUS/
Modbus communications or with a communication option.
0 ms
(0 - 100 ms)
324
H5-20
(0B57)
Communication
Parameters Reload
Sets the function to immediately enable updated MEMOBUS/Modbus communications
parameters.
0 : Reload at Next Power Cycle
1 : Reload Now
0
(0, 1)
325
H5-22
(11CF)
Speed Search from
MODBUS
Enables the MEMOBUS/Modbus communication register Speed Search function (bit0
of 15DFH).
0 : Disabled
1 : Enabled
0
(0, 1)
325
H5-25
(1589)
RUN
Function 5A Register 1
Selection
Returns the contents of the specified MEMOBUS/Modbus communications register
when responding to the master device.
0044H (U1-05)
(0000H - FFFFH)
325
H5-26
(158A)
RUN
Function 5A Register 2
Selection
Returns the contents of the specified MEMOBUS/Modbus communications register
when responding to the master device.
0045H (U1-06)
(0000H - FFFFH)
325
H5-27
(158B)
RUN
Function 5A Register 3
Selection
Returns the contents of the specified MEMOBUS/Modbus communications register
when responding to the master device.
0042H (U1-03)
(0000H - FFFFH)
325
H5-28
(158C)
RUN
Function 5A Register 4
Selection
Returns the contents of the specified MEMOBUS/Modbus communications register
when responding to the master device.
0049H (U1-10)
(0000H - FFFFH)
326
◆ H6: Pulse Train Input/Output
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H6-02
(042D)
RUN
Terminal RP Frequency
Scaling
Sets the frequency of the pulse train input signal used when the item selected with H6-
01 [Terminal RP Pulse Train Function] is input at 100%.
1440 Hz
(100 - 32000 Hz)
326
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
V/f
OLV
