◆ C1: Accel & Decel Time
No.
(Hex.)
Name Description
Default
(Range)
Ref.
C1-01
(0200)
RUN
Acceleration Ramp 1
Sets the ramp to accelerate from zero to maximum output speed.
1.50 s
(0.00 - 600.00 s)
289
C1-02
(0201)
RUN
Deceleration Ramp 1
Sets the ramp to decelerate from maximum output speed to zero.
1.50 s
(0.00 - 600.00 s)
289
C1-03
(0202)
RUN
Acceleration Ramp 2
Sets the ramp to accelerate from zero to maximum output speed.
1.50 s
(0.00 - 600.00 s)
289
C1-04
(0203)
RUN
Deceleration Ramp 2
Sets the ramp to decelerate from maximum output speed to zero.
1.50 s
(0.00 - 600.00 s)
289
C1-05
(0204)
RUN
Acceleration Ramp 3
Sets the ramp to accelerate from zero to maximum output speed.
1.50 s
(0.00 - 600.00 s)
289
C1-06
(0205)
RUN
Deceleration Ramp 3
Sets the ramp to decelerate from maximum output speed to zero.
1.50 s
(0.00 - 600.00 s)
289
C1-07
(0206)
RUN
Acceleration Ramp 4
Sets the ramp to accelerate from zero to maximum output speed.
1.50 s
(0.00 - 600.00 s)
290
C1-08
(0207)
RUN
Deceleration Ramp 4
Sets the ramp to decelerate from maximum output speed to zero.
1.50 s
(0.00 - 600.00 s)
290
C1-09
(0208)
RUN
Fast Stop Ramp
Sets the ramp that the drive will decelerate to zero for Emergency Stop.
Note:
• Decelerating too quickly can cause an ov [Overvoltage] fault that shuts off the
drive while the motor to coasts to a stop. Set a Fast Stop time in C1-09 that
prevents motor coasting and makes sure that the motor stops quickly and safely.
• When L2-29 = 0 [Kinetic Energy Backup Method = Single Drive KEB Ride-Thru
1] and you do KEB Auto-Tuning, the drive will automatically set C1-09. If you
must not change the Fast Stop time, do not do KEB Tuning.
1.50 s
(0.00 - 600.00 s)
290
C1-10
(0209)
Accel/Decel Time
Setting Units
Sets the setting units for C1-01 to C1-08 [Accel/Decel Times 1 to 4], C1-09 [Fast Stop
Time], L2-06 [Kinetic Energy Backup Decel Time], and L2-07 [Kinetic Energy Backup
Accel Time].
0 : 0.01 s (0.00 to 600.00 s)
1 : 0.1 s (0.0 to 6000.0 s)
0
(0, 1)
290
C1-11
(020A)
Accel/Decel Switching
Speed
Sets the speed at which the drive will automatically change acceleration and
deceleration times.
0.0%
(0.0 - 100.0%)
290
C1-15
(0260)
Inspect Dec Ramp
Sets the deceleration ramp used for inspection run.
0.00 s
(0.00 - 2.00 s)
291
◆ C2: Jerk Characteristics
No.
(Hex.)
Name Description
Default
(Range)
Ref.
C2-01
(020B)
Jerk at Accel Start
Sets the jerks acceleration time at start.
0.50 s
(0.00 - 10.00 s)
291
C2-02
(020C)
Jerk at Accel End
Sets the jerk acceleration time at completion.
0.50 s
(0.00 - 10.00 s)
291
C2-03
(020D)
Jerk at Decel Start
Sets the jerk deceleration time at start.
0.50 s
(0.00 - 10.00 s)
291
C2-04
(020E)
Jerk at Decel End
Sets the jerk deceleration time at completion.
0.50 s
(0.00 - 10.00 s)
291
C2-05
(020F)
Jerk below Leveling
Speed
Sets the jerk deceleration time below leveling speed.
0.50 s
(0.00 - 10.00 s)
292
